Case Studies-Thermal Solution Design
We will use professional thermal analysis software to design the optimal scheme for customers, then confirm the feasibility of the theory with engineers, and then start to make samples for testing
Project Details
Customer:
Energy storage manufacturer
Application:
Photovoltaic industry
Technology:
Soldering process with heat pipes
Thermal power type:
IGBT cooling
Location:
USA
Intruduction
Our engineers analyzed the customer's demand when they got it. Since the power is 4100W, forced convection must be adopted, and one fan should be selected. Since the customer's space size is relatively small, the fans must have high efficiency and large air volume. At the same time, the heating source is the 4100w, where the heat is concentrated, so the heat pipe with high efficiency must be used for local heat distribution and diffusion and heat removal.
The Thermal Solution
Designed requirements
The total thermal power two operation
modes:2052*2=4104W;
Fan flow rate is 9.16 m³/min(550 m³/h);
The maximum surface temperature of the
heat sink is less than 105 degrees;
Ambient temperature is 50 ℃;
Skived fin process for the heat sink;
8 pcs D9.5mm Heat pipes;
Designed requirements
Designed requirements
To solve the function calculation equation, make each curve function equation convergent based on the set parameters
After the software is run, the air volume pressure is obtained, so as to determine a reference value for the fan resistance impedance in the later period
Also, after the software is run, the speed of the air volume is obtained, so as to determine a reference value for the later fan air volume
After calculation, the temperature distribution diagram of the heat source within the range of the set module is obtained, and then the engineer can optimize it.
Results
Our engineers use detailed data and accurate meshing CFD software for calculation. By constantly adjusting the data module, heat pipe position, and thickness and spacing of heat sinks fins, we finally designed a heat sink scheme meeting the requirements for the customer. Meanwhile, we have made sample testing and mass production. However, the heat pipe heat sink should be noted that in extreme environment, the liquid inside the heat pipe is easy to freeze and then expand. The location and gravity direction of the main heat pipe are required
