36W Peltier Air Conditiner-TEA00017
Heat pipes heat sink for hot surface cooling.Skived fin heat sink for cold surface. Efficient 9025 fan for driving air flow.Compress suitable anti condensation foam.
Introduction:
The TEA00017 is Kenfat ech standard Thermoelectric Cooler Assembly that heat dissipated by air in both sides. It provides active theraml soulation to objects of customer application. The hot sides used one high technology thermal conductivity heat sink and high reliability fan for heat transferring. And the cold side also used one high thermal conductivity heat sink and high reliability fan for heat transferring. The heat pumping action is took by thermoelectric modules, which is big brand, Ferrotec or Laird. High COP more than 0.8, the power consuption of the unit is about 43.7watts, and cooling perfromance more than 36watts at dT in 0℃ and ambient tempeature in 35℃.
Introduction:
The ID-035-12-AA is Kenfat ech standard Thermoelectric Cooler Assembly that heat dissipated by air in both sides. It provides active theraml soulation to objects of customer application. The hot sides used one high technology thermal conductivity heat sink and high reliability fan for heat transferring. And the cold side also used one high thermal conductivity heat sink and high reliability fan for heat transferring. The heat pumping action is took by thermoelectric modules, which is big brand, Ferrotec or Laird. High COP more than 0.8, the power consuption of the unit is about 43.7watts, and cooling perfromance more than 36watts at dT in 0℃ and ambient tempeature in 35℃.
Application:
. Medical diagnostics
. Industrial Laser
. Mdeical application
. Analytical Instrumentation
. High-performance Liquid Chromatography (HPLC)
Technology Specification
Production application: Indoor
Cooling power Max (w) :47.5w, @ 35°C, dT=0°C
Operation Voltage (VDC):12VDC (Max 15VDC)
Current (A):Normal 3.64A, Initial 4.2A
Total power consumption (w):43.7w
COP>0.8
Performance Tolerance (±%):±10%
Hold side thermal dissipated:Force convertion by Axial fan
Cold side thermal dissipated:Force convertion by Axial fan
Over temperature (hot side):75°C
Operation temperature range:-10-55°C
IP Level:None
Fan MTBF:70,000hours @40℃, 65%RH
Noise level:<40dB(A)
Certification Compliance:RoHS
Weight (kg):0.90
Performance Curve
Dimension Information (unit:mm)
Installation & Service Requirement
1,Installation and used the unit in indoor.
2,The Units is mounted in a cabinet and hot side is towards externally.
3,Used 2-M4 mechanical screw, tooth washers and flat washers for assembly.
4,Suitable cabinet cutout size 82x102mm.
5,Enough insulation to cabinet is important, it will have good performance from the unit, recommend 5-20mm.
6,Power input 12VDC.Clean the fan impellers and heat sink regular, to keep the good heat transfer. ( Brush or Air to remove the dust, No water).
7,Used a fuse in line to protect input power lines.
8,Any installation question, please contact kenfatech service by telephone.
Safety & Warning
1,Assemble the unit properly, mounted the unit in vertical direction, make sure the condensation water flow out from heat sink fins if in condensation condition.
2,Don’t input incorrect voltage to this unit.
3,Handle the unit carefully, to avoid damage and hurt by the falling out.
